The PIC16F716 is a compact yet powerful 8-bit microcontroller (MCU) developed by Microchip Technology, widely deployed in industrial control, home automation, and sensor-driven applications. Designed with cost efficiency and simplicity in mind, this MCU features a Flash-based program memory, internal EEPROM, analog comparators, and an integrated oscillator—all in a compact 18-pin package. While ideal for embedded systems, its protected firmware often presents challenges when data recovery or firmware duplication is necessary.

At CIRCUIT ENGINEERING CO., LTD, we specialize in offering advanced reverse engineering services to break chip PIC16F716 heximal files. This includes the ability to crack, decode, and decrypt protected program memory and EEPROM data from the chip, even when the device is secured or locked using Microchip’s code protection mechanisms.

Break Chip PIC16F716 and extract Heximal out from MCU PIC16F716 flash memory, the security fuse bit of Microcontroller PIC16F716 can be removed or disable for the original MCU PIC16F716;

When clients need access to the firmware inside the PIC16F716, standard reading tools often fail due to built-in encryption and lock bits. Our team uses proprietary techniques and hardware-level exploit strategies to unlock and copy the embedded binary or heximal file from Flash or EEPROM memory. Once recovered, the data can be converted into a source code archive for analysis, debugging, or replication.

Our services cover a full range of tasks, including:

• Crack and unlock code-protected memory areas
• Restore lost or corrupted firmware from embedded devices
• Duplicate or clone firmware for hardware replacement or scale-up production
• Decrypt and decode the program file into human-readable logic
• Generate commented disassemblies or higher-level reconstructions from raw memory dumps

Microcontroller Core Features:

· High-performance RISC CPU

· Only 35 single-word instructions to learn

– All single-cycle instructions except for

program branches which are two-cycle

· Operating speed: DC – 20 MHz clock input

DC – 200 ns instruction cycle

· Interrupt capability (up to 7 internal/external interrupt sources)

· 8-level deep hardware stack

· Direct, Indirect and Relative Addressing modes

Special Microcontroller Features:

· Power-on Reset (POR)

· Power-up Timer (PWRT) and

Oscillator Start-up Timer (OST)

· Watchdog Timer (WDT) with its own on-chip RC

oscillator for reliable operation

· Dual level Brown-out Reset circuitry

– 2.5 VBOR (Typical)

– 4.0 VBOR (Typical)

· Programmable code protection

· Power-Saving Sleep mode

· Selectable oscillator options

· Fully static design

· In-Circuit Serial Programming™ (ICSP™)

CMOS Technology:

· Wide operating voltage range:

– Industrial: 2.0V to 5.5V

– Extended: 3.0V to 5.5V

· High Sink/Source Current 25/25 mA

· Wide temperature range:

– Industrial: -40°C to 85°C

– Extended: -40°C to 125°C

Low-Power Features:

· Standby Current:

– 100 nA @ 2.0V, typical

· Operating Current:

– 14 ìA @ 32 kHz, 2.0V, typical

– 120 ìA @ 1 MHz, 2.0V, typical

– 1 ìA @ 2.0V, typical

· Timer1 Oscillator Current:

– 3.0 ìA @ 32 kHz, 2.0V, typical

The PIC16F716 is tailored for real-time control in resource-constrained environments. With features like:

• 2K words of Flash program memory
• 128 bytes of EEPROM
• 128 bytes of RAM
• Internal 4 MHz oscillator
• Multiple analog comparators

…it is often used in low-cost embedded control applications such as:

• Home appliance control boards
• Power supplies and battery charging circuits
• Environmental monitoring and sensor hubs
• Automotive lighting and low-level control logic

This makes the PIC16F716 a prime candidate for firmware copying, especially when systems are no longer supported or require restoration after hardware failure.

Why Choose Our Reverse Engineering Solutions?

Many businesses, repair engineers, or developers face the urgent need to recover firmware from a locked, secured, or encrypted PIC16F716 chip. That’s where our deep expertise in firmware disassembly, memory analysis, and protected data extraction becomes invaluable.

We maintain strict confidentiality and legal compliance while providing efficient, low-risk firmware recovery services. Whether you’ve lost the original source files or need to duplicate a critical control board, we can extract, decrypt, and return the full heximal program archive to you in a readable format.

Peripheral Features:

· Timer0: 8-bit timer/counter with 8-bit prescaler  can be incremented during Sleep via external crystal/clock

· Timer2: 8-bit timer/counter with 8-bit period register, prescaler and postscaler

· Enhanced Capture, Compare, PWM module:

– Capture is 16-bit, max. resolution is 12.5 ns

– Compare is 16-bit, max. resolution is 200 ns

– PWM maximum resolution is 10-bit

– Enhanced PWM:

– Single, Half-Bridge and Full-Bridge modes

– Digitally programmable dead-band delay

– Auto-shutdown/restart

· 8-bit multi-channel Analog-to-Digital Converter

· 13 I/O pins with individual direction control

· Programmable weak pull-ups on PORTB

Our “break chip PIC16F716 heximal” service empowers you to regain control over your embedded systems by opening up protected memory, restoring lost firmware, and enabling you to clone or copy the program data for future use. Don’t let a locked microcontroller stop your operations—contact [Your Company Name] today for professional, discrete, and highly accurate firmware recovery services tailored to your needs.
