The following section intends to give an overview of the basic features of the STM8S003F3/K3 value line functional modules and peripherals. For more detailed information please refer to the corresponding family reference manual (RM0016).

The 8-bit STM8 core is designed for code efficiency and performance. It contains six internal registers which are directly addressable in each execution context, 20 addressing modes including indexed indirect and relative addressing and 80 instructions.

Harvard architecture

3-stage pipeline

32-bit wide program memory bus – single cycle fetching for most instructions

X and Y 16-bit index registers – enabling indexed addressing modes with or without offset and read-modify-write type data manipulations

8-bit accumulator

24-bit program counter – 16-Mbyte linear memory space

16-bit stack pointer – access to a 64 K-level stack

8-bit condition code register – 7 condition flags for the result of the last instruction

20 addressing modes

Indexed indirect addressing mode for look-up tables located anywhere in the address space when restoring microcontroller stm32f103c8 flash memory code

Stack pointer relative addressing mode for local variables and parameter passing

80 instructions with 2-byte average instruction size

Standard data movement and logic/arithmetic functions

8-bit by 8-bit multiplication

16-bit by 8-bit and 16-bit by 16-bit division

Bit manipulation

Data transfer between stack and accumulator (push/pop) with direct stack access after restore stm32f103c6 mcu flash full content;

Data transfer using the X and Y registers or direct memory-to-memory transfers
