Decap Microchip PIC18F1320 Processor and then extract flash and eeprom memory content from pic18f1320 mcu chip, the source code will be copied embedded firmware from pic18f1320 microcontroller flash memory,

All of the devices in the PIC18F1220/1320 family offer nine different oscillator options, allowing users a wide range of choices in developing application hardware. These include:

Four Crystal modes, using crystals or ceramic resonators.

Two External Clock modes, offering the option of using two pins (oscillator input and a divide-by-4 clock output), or one pin (oscillator input, with the second pin reassigned as general I/O).

Two External RC Oscillator modes, with the same pin options as the External Clock modes.

An internal oscillator block, which provides an 8 MHz clock (±2% accuracy) and an INTRC source (approximately 31 kHz, stable over temperature and VDD), as well as a range of six user-selectable clock frequencies (from 125 kHz to 4 MHz) for a total of 8 clock frequencies.

decap Microchip PIC18F1320 processador e, em seguida, extrair flash e eeprom conteúdo de memória de pic18f1320 mcu chip, o código-fonte será copiado firmware incorporado da memória flash do microcontrolador pic18f1320,

Besides its availability as a clock source, the internal oscillator block provides a stable reference source that gives the family additional features for robust operation:

Fail-Safe Clock Monitor: This option constantly monitors the main clock source against a reference signal provided by the internal oscillator. If a clock failure occurs by recovering pic18f1330 microchip mcu source code, the controller is switched to the internal oscillator block, allowing for continued low-speed operation, or a safe application shutdown.

Two-Speed Start-up: This option allows the internal oscillator to serve as the clock source from Power- on Reset, or wake-up from Sleep mode, until the primary clock source is available in the process of attacking pic18f13k50 microcontroller flash memory. This allows for code execution during what would otherwise be the clock start-up interval and can even allow an application to perform routine background activities and return to Sleep without returning to full-power operation.
