PostHeaderIcon Reverse Engineering Microcontroller PIC16C717 Program

We can Reverse engineering Microcontroller PIC16C717 Program, please view the Microcontroller PIC16C717 features for your reference:

Microcontroller Core Features:

· High-performance RISC CPU

· Only 35 single word instructions to learn

· All single cycle instructions except for program branches which are two cycle

· Operating speed: DC – 20 MHz clock input

· Interrupt capability (up to 10 internal/external interrupt sources)

· Eight level deep hardware stack to prove the difficulty of Read CPLD Chip Microcontroller IC JED

· Direct, indirect and relative addressing modes

· Power-on Reset (POR)

· Power-up Timer (PWRT) and Oscillator Start-up Timer (OST)

· Watchdog Timer (WDT) with its own on-chip RC oscillator for reliable operation when Extract PLD Chip Eeprom

· Selectable oscillator options:

– INTRC – Internal RC, dual speed (4MHz and 37KHz) dynamically switchable for power savings

– ER – External resistor, dual speed (user selectable frequency and 37KHz) dynamically switchable for power savings

– EC – External clock

– HS – High speed crystal/resonator

– XT – Crystal/resonator

– LP – Low power crystal

· Low-power, high-speed CMOS EPROM technology which can help to ease the process of Copy CPLD MCU software data

· In-Circuit Serial Programming™ (ISCP)

· Wide operating voltage range: 2.5V to 5.5V

· 15 I/O pins with individual control for:

– Direction (15 pins)

– Digital/Analog input (6 pins)

– PORTB interrupt on change (8 pins)

– PORTB weak pull-up (8 pins)

– High voltage open drain (1 pin)

· Commercial and Industrial temperature ranges

· Low-power consumption:

– < 2 mA @ 5V, 4 MHz

– 22.5 µA typical @ 3V, 32 kHz

· Timer0: 8-bit timer/counter with 8-bit prescaler

· Timer1: 16-bit timer/counter with prescaler, can be incremented during sleep via external crystal/clock

· Timer2: 8-bit timer/counter with 8-bit period register, prescaler and postscaler

· Enhanced Capture, Compare, PWM (ECCP) module

– Capture is 16 bit, max. resolution is 12.5 ns

– Compare is 16 bit, max. resolution is 200 ns

– PWM max. resolution is 10 bit

– Enhanced PWM:

– Single, Half-Bridge and Full-Bridge output modes

– Digitally programmable deadband delay

· Analog-to-Digital converter:

– PIC16C770/771 12-bit resolution

– PIC16C717 10-bit resolution

· On-chip absolute bandgap voltage reference generator

· Programmable Brown-out Reset (PBOR) circuitry

· Programmable Low-Voltage Detection (PLVD) circuitry

· Master Synchronous Serial Port (MSSP) with two modes of operation:

– 3-wire SPI™ (supports all 4 SPI modes)

– I2C™ compatible including master mode support only

· Program Memory (PMR) capability for look-up table, character string storage and checksum calculation purposes
