Microchip’s AT89C51RE2 is a high-performance 8-bit microcontroller based on the popular 8051 core. Designed for embedded applications requiring robust control, this chip features advanced memory architecture, including 128KB of flash, EEPROM, and RAM. Commonly used in automotive electronics, industrial control systems, and communication devices, it offers powerful capabilities in a compact form factor. But once programmed and deployed, its firmware is often protected, encrypted, or locked—making recovery of the original code a technical challenge.

At CIRCUIT ENGINEERING CO.,LTD, we specialize in offering secure, professional services to copy Microcontroller AT89C51RE2 binary files, enabling end-users to clone, duplicate, or restore the firmware, flash, EEPROM, or memory data from these locked devices. Whether for system backup, migration, or legacy support, we help clients unlock and recover heximal or binary files from their embedded controllers—especially when source code or original archives are lost or unavailable.

The AT89C51RE2 microcontroller includes on-chip In-System Programming (ISP), UARTs, SPI, watchdog timer, and up to 36 I/Os, making it a versatile choice for embedded design engineers. Its secured flash memory and programmable security bits are designed to prevent unauthorized access to critical code or intellectual property. This security feature, while important, often becomes a hurdle for businesses attempting to maintain or repurpose legacy systems without original documentation.

Our service is aimed at decoding, decrypting, and opening the protected layers of this microcontroller to retrieve the full functional firmware. With years of experience in reverse engineering embedded systems, our team has developed proprietary methodologies and hardware setups capable of performing reliable, non-destructive firmware extraction.

Copy Microcontroller AT89C51RE2 Binary from its flash and eeprom memory, then replicate the program and data to other blank MCU AT89C51RE2 for the same functions;

· 80C52 Compatible

– 8051 Instruction Compatible

– Four 8-bit I/O Ports (44 Pins Version)

– Three 16-bit Timer/Counters

– 256 bytes Scratch Pad RAM

– 11 Interrupt Sources With 4 Priority Levels if Copy Microcontroller

ISP (In-System Programming) Using Standard VCC Power Supply

Integrated Power Monitor (POR/PFD) to Supervise Internal Power Supply

Boot ROM Contains Serial Loader for In-System Programming

High-speed Architecture

– In Standard Mode:

40 MHz (Vcc 2.7V to 5.5V, Both Internal and External Code Execution)

60 MHz (Vcc 4.5V to 5.5V and Internal Code Execution Only)

– In X2 Mode (6 Clocks/Machine Cycle)

20 MHz (Vcc 2.7V to 5.5V, Both Internal and External Code Execution)

30 MHz (Vcc 4.5V to 5.5V and Internal Code Execution Only)

128K bytes On-chip Flash Program/Data Memory

– 128 bytes Page Write with auto-erase

– 100k Write Cycles

On-chip 8192 bytes Expanded RAM (XRAM)

– Software Selectable Size (0, 256, 512, 768, 1024, 1792, 2048, 4096, 8192 bytes)

Dual Data Pointer

Extended stack pointer to 512 bytes

Variable Length MOVX for Slow RAM/Peripherals

Improved X2 Mode with Independant Selection for CPU and Each Peripheral

Keyboard Interrupt Interface on Port 1

SPI Interface (Master/Slave Mode)

8-bit Clock Prescaler

Programmable Counter Array with:

– High Speed Output

– Compare/Capture

– Pulse Width Modulator

– Watchdog Timer Capabilities

Asynchronous Port Reset

Two Full Duplex Enhanced UART with Dedicated Internal Baud Rate Generator

Low EMI (inhibit ALE)

Hardware Watchdog Timer (One-time Enabled with Reset-Out), Power-Off Flag

Power Control Modes: Idle Mode, Power-down Mode

Power Supply: 2.7V to 5.5V

Temperature Ranges: Industrial (-40 to +85°C)

Packages: PLCC44, VQFP44
