PostHeaderIcon Attack IC TMS320F28232PGFA Software

Attack IC TMS320F28232PGFA DSP MCU, reset the status of DSP Microcontroller TMS320F28232PGFA from locked to unlocked one through MCU cracking process, software of MCU’s flash memory can readout;

Attack IC TMS320F28232PGFA DSP MCU, reset the status of DSP Microcontroller TMS320F28232PGFA from locked to unlocked one through MCU cracking process, software of MCU's flash memory can readout

Attack IC TMS320F28232PGFA DSP MCU, reset the status of DSP Microcontroller TMS320F28232PGFA from locked to unlocked one through MCU cracking process, software of MCU’s flash memory can readout

· High-Performance Static CMOS Technology

– Up to 150 MHz (6.67-ns Cycle Time)

– 1.9-V/1.8-V Core, 3.3-V I/O Design

· High-Performance 32-Bit CPU (TMS320C28x)

– IEEE-754 Single-Precision Floating-Point

Unit (FPU) (F2833x only)

– 16 x 16 and 32 x 32 MAC Operations

– 16 x 16 Dual MAC

– Harvard Bus Architecture

– Fast Interrupt Response and Processing

– Unified Memory Programming Model

– Code-Efficient (in C/C++ and Assembly)

· Six-Channel DMA Controller (for ADC, McBSP, ePWM, XINTF, and SARAM)

· 16-Bit or 32-Bit External Interface (XINTF)

– Over 2M x 16 Address Reach

· On-Chip Memory

– F28335, F28235: 256K x 16 Flash, 34K x 16 SARAM

– F28334, F28234: 128K x 16 Flash, 34K x 16 SARAM

– F28332, F28232: 64K x 16 Flash, 26K x 16 SARAM

– 1K x 16 OTP ROM

· Boot ROM (8K x 16)

– With Software Boot Modes (via SCI, SPI, CAN, I2C, McBSP, XINTF, and Parallel I/O)

– Standard Math Tables

· Clock and System Control

– Dynamic PLL Ratio Changes Supported

– On-Chip Oscillator

– Watchdog Timer Module

· GPIO0 to GPIO63 Pins Can Be Connected to One of the Eight External Core Interrupts

· Peripheral Interrupt Expansion (PIE) Block That Supports All 58 Peripheral Interrupts

· 128-Bit Security Key/Lock

– Protects Flash/OTP/RAM Blocks

– Prevents Firmware Reverse Engineering



· Enhanced Control Peripherals

– Up to 18 PWM Outputs

– Up to 6 HRPWM Outputs With 150 ps MEP Resolution

– Up to 6 Event Capture Inputs

– Up to 2 Quadrature Encoder Interfaces

– Up to 8 32-Bit Timers

(6 for eCAPs and 2 for eQEPs)

– Up to 9 16-Bit Timers

(6 for ePWMs and 3 XINTCTRs)

· Three 32-Bit CPU Timers

· Serial Port Peripherals

– Up to 2 CAN Modules

– Up to 3 SCI (UART) Modules

– Up to 2 McBSP Modules (Configurable as SPI)

– One SPI Module

– One Inter-Integrated-Circuit (I2C) Bus

· 12-Bit ADC, 16 Channels

– 80-ns Conversion Rate

– 2 x 8 Channel Input Multiplexer

– Two Sample-and-Hold

– Single/Simultaneous Conversions

– Internal or External Reference

· Up to 88 Individually Programmable, Multiplexed GPIO Pins With Input Filtering

· JTAG Boundary Scan Support (1)

· Advanced Emulation Features

– Analysis and Breakpoint Functions

– Real-Time Debug via Hardware

· Development Support Includes

– ANSI C/C++ Compiler/Assembler/Linker

– Code Composer Studio™ IDE

– DSP/BIOS™

– Digital Motor Control and Digital Power Software Libraries

Low-Power Modes and Power Savings

– IDLE, STANDBY, HALT Modes Supported

– Disable Individual Peripheral Clocks

· Endianness: Little Endian

· Package Options:

– Lead-free, Green Packaging

– Low-Profile Quad Flatpack (PGF, PTP)

– MicroStar BGA™ (ZHH)

– Plastic BGA (ZJZ)

· Temperature Options:

– A: –40°C to 85°C (PGF, ZHH, ZJZ)

– S: –40°C to 125°C (PTP, ZJZ)

– Q: –40°C to 125°C (PTP, ZJZ)
