High Performance, Low Power AVR® 8-Bit Microcontroller

Advanced RISC Architecture

– 123 Powerful Instructions – Most Single Clock Cycle Execution

– 32 x 8 General Purpose Working Registers

– Fully Static Operation

Non-volatile Program and Data Memories

– 2/4/8K Byte of In-System Programmable Program Memory Flash

(ATtiny261/461/861)

Endurance: 10,000 Write/Erase Cycles if recovr stm32f107rct6 IC

– 128/256/512 Bytes In-System Programmable EEPROM (ATtiny261/461/861)

Endurance: 100,000 Write/Erase Cycles

– 128/256/512 Bytes Internal SRAM (ATtiny261/461/861)

– Programming Lock for Self-Programming Flash Program and EEPROM Data Security

Peripheral Features

– 8/16-bit Timer/Counter with Prescaler and Two PWM Channels

– 8/10-bit High Speed Timer/Counter with Separate Prescaler

3 High Frequency PWM Outputs with Separate Output Compare Registers

Programmable Dead Time Generator

– Universal Serial Interface with Start Condition Detector when copy at89s8252 flash memory content

– 10-bit ADC

11 Single Ended Channels

16 Differential ADC Channel Pairs

15 Differential ADC Channel Pairs with Programmable Gain (1x, 8x, 20x, 32x)

– Programmable Watchdog Timer with Separate On-chip Oscillator

– On-chip Analog Comparator

Special Microcontroller Features

– debugWIRE On-chip Debug System

– In-System Programmable via SPI Port

– External and Internal Interrupt Sources

– Low Power Idle, ADC Noise Reduction, and Power-down Modes

– Enhanced Power-on Reset Circuit

– Programmable Brown-out Detection Circuit

– Internal Calibrated Oscillator

I/O and Packages

– 16 Programmable I/O Lines

– 20-pin PDIP, 20-pin SOIC and 32-pad MLF

Operating Voltage:

– 1.8 – 5.5V for ATtiny261V/461V/861V

– 2.7 – 5.5V for ATtiny261/461/861

Speed Grade:

– ATtiny261V/461V/861V: 0 – 4 MHz @ 1.8 – 5.5V, 0 – 10 MHz @ 2.7 – 5.5V

– ATtiny261/461/861: 0 – 10 MHz @ 2.7 – 5.5V, 0 – 20 MHz @ 4.5 – 5.5V

– Active Mode: 1 MHz, 1.8V: 380ìA

– Power-down Mode: 0.1ìA at 1.8V

Typical values contained in this data sheet are based on simulations and characterization of other AVR microcontrollers manufactured on the same process technology. Min and Max values will be available after the device is characterized before Break IC.

The ATtiny261/461/861 is a low-power CMOS 8-bit microcontroller based on the AVR enhanced RISC architecture. By executing powerful instructions in a single clock cycle, the ATtiny261/461/861 achieves throughputs approaching 1 MIPS per MHz allowing the system designer to optimize power consumption versus processing speed after Break IC.
