Attack MCU MSP430G2452IPW14R Heximal

Attack MCU MSP430G2452IPW14R flash memory and extract heximal from Microcontroller MSP430G2452, the status of Microprocessor will be reset from locked to open one after get access to the databus

Attack MCU MSP430G2452IPW14R flash memory and extract heximal from Microcontroller MSP430G2452, the status of Microprocessor will be reset from locked to open one after get access to the databus

Attack MCU MSP430G2452IPW14R flash memory and extract heximal from Microcontroller MSP430G2452, the status of Microprocessor will be reset from locked to open one after get access to the databus;

FEATURES

Low Supply Voltage Range: 1.8 V to 3.6 V

Ultra-Low Power Consumption

– Active Mode: 220 µA at 1 MHz, 2.2 V

– Standby Mode: 0.5 µA

– Off Mode (RAM Retention): 0.1 µA

Five Power-Saving Modes

Ultra-Fast Wake-Up From Standby Mode in Less Than 1 µs

16-Bit RISC Architecture, 62.5-ns Instruction Cycle Time Basic Clock Module Configurations

– Internal Frequencies up to 16 MHz With

Four Calibrated Frequencies

– Internal Very-Low-Power Low-Frequency (LF) Oscillator

– 32-kHz Crystal

– External Digital Clock Source

One 16-Bit Timer_A With Three Capture/Compare Registers

Up to 16 Touch-Sense Enabled I/O Pins

Universal Serial Interface (USI) Supporting SPI and I2C

10-Bit 200-ksps Analog-to-Digital (A/D)

Converter With Internal Reference, Sample-and-Hold, and Autoscan (MSP430G2x52 Only)

On-Chip Comparator for Analog

Brownout Detector Serial Onboard Programming,

No External Programming Voltage Needed,

Programmable Code Protection by Security Fuse

On-Chip Emulation Logic With Spy-Bi-Wire Interface

Family Members are Summarized in Table 1 Package Options

– TSSOP: 14 Pin, 20 Pin

– PDIP: 20 Pin

– QFN: 16 Pin

For Complete Module Descriptions, See the MSP430x2xx Family User’s Guide (SLAU144)
