Reverse Engineering Microcontroller PIC16HV610 is a process to locate the fuse bit of mcu and unlock pic16hv610 protection, extract mcu code from pic16hv610 memory;

Reverse Engineering Microcontroller PIC16HV610 Program
Reverse Engineering Microcontroller PIC16HV610 Program

Reverse Engineering Microcontroller PIC16HV610 Program

We can Reverse engineering Microcontroller PIC16HV610 Program, please view the Microcontroller PIC16HV610 features for your reference:

High-Performance RISC CPU:

· Only 35 instructions to learn:

– All single-cycle instructions except branches

· Operating speed:

– DC – 20 MHz oscillator/clock input

– DC – 200 ns instruction cycle

· Interrupt capability

· 8-level deep hardware stack

· Direct, Indirect and Relative Addressing modes

Special Microcontroller Features:

· Precision Internal Oscillator:

– Factory calibrated to ±1%, typical

– User selectable frequency: 4 MHz or 8 MHz

· Power-Saving Sleep mode

· Voltage range:

– PIC16F610/616: 2.0V to 5.5V

– PIC16HV610/616: 2.0V to user defined maximum (see note)

· Industrial and Extended Temperature range

· Power-on Reset (POR)

· Power-up Timer (PWRT) and Oscillator Start-up Timer (OST)

· Brown-out Reset (BOR)

· Watchdog Timer (WDT) with independent oscillator for reliable operation before Reverse engineering Microcontroller

· Multiplexed Master Clear with pull-up/input pin

· Programmable code protection

· High Endurance Flash:

– 100,000 write Flash endurance

– Flash retention: > 40 years

Low-Power Features:

· Standby Current:

– 50 nA @ 2.0V, typical

· Operating Current:

– 20 ìA @ 32 kHz, 2.0V, typical

– 220 ìA @ 4 MHz, 2.0V, typical

· Watchdog Timer Current:

– 1 ìA @ 2.0V, typical

Peripheral Features:

· Shunt Voltage Regulator (PIC16HV610/616 only):

– 5 volt regulation

– 4 mA to 50 mA shunt range

· 11 I/O pins and 1 input only

– High current source/sink for direct LED drive

– Interrupt-on-Change pins

– Individually programmable weak pull-ups

· Analog Comparator module with:

– Two analog comparators

– Programmable on-chip voltage reference (CVREF) module (% of VDD)

– Fixed Voltage Reference

– Comparator inputs and outputs externally accessible

– SR Latch

– Built-In Hysteresis (user selectable)

· Timer0: 8-bit timer/counter with 8-bit programmable prescaler

· Enhanced Timer1:

– 16-bit timer/counter with prescaler

– External Timer1 Gate (count enable)

– Option to use OSC1 and OSC2 in LP mode as Timer1 oscillator if INTOSC mode selected

– Timer1 oscillator

· In-Circuit Serial ProgrammingTM (ICSPTM) via two pins

attack Microcontroller PIC16HV610 memory protection to restore the embedded firmware from it
attack Microcontroller PIC16HV610 memory protection to restore the embedded firmware from it

PIC16F616/16HV616 only:

· A/D Converter:

– 10-bit resolution

– 8 external input channels

– 2 internal reference channels

· Timer2: 8-bit timer/counter with 8-bit period register, prescaler and postscaler

· Enhanced Capture, Compare, PWM module:

– 16-bit Capture, max. resolution 12.5 ns

– 16-bit Compare, max. resolution 200 ns

– 10-bit PWM with 1, 2 or 4 output channels, programmable “dead time”, max. frequency 20 kHz
