Copy IC PIC12C671 Eeprom


We can Copy IC PIC12C671 Eeprom, please view the IC PIC12C671 features for your reference:

High-Performance RISC CPU:


· Only 35 single word instructions to learn

· All instructions are single cycle (400 ns) except for program branches which are two-cycle

· Operating speed: DC – 10 MHz clock input DC – 400 ns instruction cycle when Copy IC

· 14-bit wide instructions 8-bit wide data path

· Interrupt capability

· Special function hardware registers

· 8-level deep hardware stack

· Direct, indirect and relative addressing modes for data and instructions if Copy IC


Peripheral Features:

· Four-channel, 8-bit A/D converter

· 8-bit real time clock/counter (TMR0) with 8-bit programmable prescaler

· 1,000,000 erase/write cycle EEPROM data memory

· EEPROM data retention > 40 years


Special Microcontroller Features:

In-Circuit Serial Programming (ICSP™)

Internal 4 MHz oscillator with programmable calibration before Copy IC

Selectable clockout

Power-on Reset (POR)

Power-up Timer (PWRT) and Oscillator Start-up

Timer (OST)

Watchdog Timer (WDT) with its own on-chip RC oscillator for reliable operation after Copy IC

Power saving SLEEP mode

Interrupt-on-pin change (GP0, GP1, GP3)

Internal pull-ups on I/O pins (GP0, GP1, GP3)

Internal pull-up on MCLR pin

Selectable oscillator options:

– INTRC: Precision internal 4 MHz oscillator for Copy IC

– EXTRC: External low-cost RC oscillator

– XT:   Standard crystal/resonator

– HS:   High speed crystal/resonator

– LP:   Power saving, low frequency crystal


CMOS Technology:

· Low-power, high-speed CMOS EPROM/EEPROM technology when Copy IC

· Fully static design

· Wide operating voltage range 2.5V to 5.5V

· Commercial, Industrial and Extended temperature ranges

· Low power consumption

< 2 mA @ 5V, 4 MHz

15 µA typical @ 3V, 32 kHz

< 1 µA typical standby current before Copy IC
