PostHeaderIcon Copy IC ATmega162 Binary

Copy IC ATmega162 Binary content and unlock avr atmega162 mcu protection,  and extract the embedded firmware from microcontroller atmega162 flash and eeprom memory;

High-performance, Low-power AVR® 8-bit Microcontroller

· Advanced RISC Architecture

– 131 Powerful Instructions – Most Single-clock Cycle Execution

– 32 x 8 General Purpose Working Registers

– Fully Static Operation

– Up to 16 MIPS Throughput at 16 MHz

– On-chip 2-cycle Multiplier

High Endurance Non-volatile Memory segments

– 16K Bytes of In-System Self-programmable Flash program memory

– 512 Bytes EEPROM

– 1K Bytes Internal SRAM

– Write/Erase cycles: 10,000 Flash/100,000 EEPROM

– Data retention: 20 years at 85°C/100 years at 25°C(1)

– Optional Boot Code Section with Independent Lock Bits

In-System Programming by On-chip Boot Program

True Read-While-Write Operation

– Up to 64K Bytes Optional External Memory Space

8-bit Microcontroller

with 16K Bytes

In-System– Programming Lock for Software Security

JTAG (IEEE std. 1149.1 Compliant) Interface

– Boundary-scan Capabilities According to the JTAG Standard

– Extensive On-chip Debug Support

– Programming of Flash, EEPROM, Fuses, and Lock Bits through the JTAG Interface

Peripheral Features

– Two 8-bit Timer/Counters with Separate Prescalers and Compare Modes

– Two 16-bit Timer/Counters with Separate Prescalers, Compare Modes, and

Capture Modes

Copy IC ATmega162 Binary content and unlock avr atmega162 mcu protection,  and extract the embedded firmware from microcontroller atmega162 flash and eeprom memory
Copy IC ATmega162 Binary content and unlock avr atmega162 mcu protection,  and extract the embedded firmware from microcontroller atmega162 flash and eeprom memory

– Real Time Counter with Separate Oscillator

– Six PWM Channels

– Dual Programmable Serial USARTs

– Master/Slave SPI Serial Interface

– Programmable Watchdog Timer with Separate On-chip Oscillator before Copy IC

– On-chip Analog Comparator

Special Microcontroller Features

– Power-on Reset and Programmable Brown-out Detection

– Internal Calibrated RC Oscillator

– External and Internal Interrupt Sources

– Five Sleep Modes: Idle, Power-save, Power-down, Standby, and Extended Standby

I/O and Packages

– 35 Programmable I/O Lines

– 40-pin PDIP, 44-lead TQFP, and 44-pad MLF

Operating Voltages

– 1.8 – 5.5V for ATmega162V

– 2.7 – 5.5V for ATmega162

Speed Grades

– 0 – 8 MHz for ATmega162V

– 0 – 16 MHz for ATmega162

Programmable Flash when BREAK IC
