Copy Chip PIC16F87 Code from the memory which include flash and eeprom, then the program will be rewrite to other blank PIC16F87 which will perform the same functions as original PIC16F87 microcontroller:

Low-Power Features:

· Power Managed modes:



Copy Chip PIC16F87 Code

Copy Chip PIC16F87 Code



Primary RUN: RC oscillator, 76 µA, 1 MHz, 2V

– RC_RUN: 7 µA, 31.25 kHz, 2V

– SEC_RUN: 9 µA, 32 kHz, 2V

– SLEEP: 0.1 µA, 2V

· Timer1 Oscillator: 1.8 µA, 32 kHz, 2V

· Watchdog Timer: 2.2 µA, 2V

· Two-Speed Oscillator Start-up Oscillators:

· Three Crystal modes:

– LP, XT, HS: up to 20 MHz

· Two External RC modes

· One External Clock mode:

– ECIO: up to 20 MHz

· Internal oscillator block:

– 8 user selectable frequencies: 31 kHz, 125 kHz, 250 kHz, 500 kHz, 1 MHz, 2 MHz, 4 MHz, 8 MHz

Peripheral Features:

· Capture, Compare, PWM (CCP) module:

– Capture is 16-bit, max. resolution is 12.5 ns

Compare is 16-bit, max. resolution is 200 ns

– PWM max. resolution is 10-bit

· 10-bit, 7-channel Analog-to-Digital Converter

· Synchronous Serial Port (SSP) with SPI™ (Master/Slave) and I2C™ (Slave)

· Addressable Universal Synchronous Asynchronous Receiver Transmitter (USART/SCI) with 9-bit address detection:

RS-232 operation using internal oscillator (no external crystal required)

· Dual Analog Comparator module:

– Programmable on-chip voltage reference

– Programmable input multiplexing from device inputs and internal voltage reference

– Comparator outputs are externally accessible

Special Microcontroller Features:

· 100,000 erase/write cycles Enhanced FLASH program memory typical

· 1,000,000 typical erase/write cycles EEPROM data memory typical

· EEPROM Data Retention: > 40 years

· In-Circuit Serial Programming™ (ICSP™) – via two pins

· Processor read/write access to program memory

· Low-Voltage Programming

· In-Circuit Debugging via two pins

· Extended Watchdog Timer (WDT):

– Programmable period from 1 ms to 268s

· Wide operating voltage range: 2.0V to 5.5V
