Break Microcontroller TI MSP430F448 can help engineer to disable the protective mechanism of MCU MSP430F448, the firmware in the flash memory can be readout directly with universal programmer, then Microprocessor MSP430F448 cloning can be proceed.

Break Microcontroller TI MSP430F448 can help engineer to disable the protective mechanism of MCU MSP430F448, the firmware in the flash memory can be readout directly with universal programmer

Break Microcontroller TI MSP430F448 can help engineer to disable the protective mechanism of MCU MSP430F448, the firmware in the flash memory can be readout directly with universal programmer

Low Supply-Voltage Range, 1.8 V to 3.6 V

Ultralow-Power Consumption:

– Active Mode: 280 µA at 1 MHz, 2.2 V

– Standby Mode: 1.1 µA

– Off Mode (RAM Retention): 0.1 µA

Five Power Saving Modes

Wake-Up From Standby Mode in 6 µs 16-Bit RISC Architecture,

125-ns Instruction Cycle Time

12-Bit A/D Converter With Internal

Reference, Sample-and-Hold and Autoscan

Feature

16-Bit Timer With Three† or Seven‡

Capture/Compare-With-Shadow Registers, Timer_B Serial Onboard Programming,

No External Programming Voltage Needed Programmable Code Protection by Security Fuse

Integrated LCD Driver for Up to 160 Segments

Family Members Include:

– MSP430F435:

16KB+256B Flash Memory,

512B RAM

– MSP430F436:

24KB+256B Flash Memory,

1KB RAM

– MSP430F437:

32KB+256B Flash Memory,

1KB RAM

16-Bit Timer With Three Capture/Compare Registers, Timer_A On-Chip Comparator Serial Communication Interface (USART), Select Asynchronous UART or Synchronous SPI by Software;

Two USARTs (USART0, USART1) In MSP430x44x Devices One USART (USART0) In MSP430x43x

Devices Brownout Detector Supply Voltage Supervisor/Monitor With Programmable Level Detection

– MSP430F447:

32KB+256B Flash Memory,

1KB RAM

– MSP430F448:

48KB+256B Flash Memory,

2KB RAM

– MSP430F449:

60KB+256B Flash Memory,

2KB RAM

For Complete Module Descriptions, See The MSP430x4xx Family User’s Guide

Literature Number SLAU056 ’F435, ’F436, and ’F437 devices ’F447, ’F448, and ’F449 devices

description

The Texas Instruments MSP430 series is an ultralow-power microcontroller family consisting of several devices featuring different sets of modules targeted to various applications. The microcontroller is designed to be battery operated for use in extended-time applications.

The MSP430 achieves maximum code efficiency with its 16-bit RISC architecture, 16-bit CPU-integrated registers, and a constant generator. The digitally-controlled oscillator provides wake-up from low-power mode to active mode in less than 6 µs.

The MSP430x43x and the MSP430x44x series are microcontroller configurations with two built-in 16-bit timers, a fast 12-bit A/D converter, one or two universal serial synchronous/asynchronous communication interfaces (USART), 48 I/O pins, and a liquid crystal driver (LCD) with up to 160 segments.

Typical applications include sensor systems that capture analog signals, convert them to digital values, and process and transmit the data to a host system, or process this data and displays it on a LCD panel. The timers make the configurations ideal for industrial control applications such as ripple counters, digital motor control, EE-meters, hand-held meters, etc. The hardware multiplier enhances the performance and offers a broad code and hardware-compatible family solution.
