Analog Peripherals

– 12-Bit ADC

·   ±1 LSB INL (C8051F52x/C8051F53x); no missing codes

·   Programmable throughput up to 200 ksps

·   Up to 6/16 external inputs

·   Data dependent windowed interrupt generator

·   Built-in temperature sensor

– Comparator

·   Programmable hysteresis and response time

·   Configurable as wake-up or reset source

·   Low current

– POR/Brownout Detector

– Voltage Reference—1.5 to 2.2 V (programmable)

On-Chip Debug

– On-chip debug circuitry facilitates full-speed, non-intrusive in-system debug (No emulator required)

– Provides breakpoints, single stepping

– Inspect/modify memory and registers

– Complete development kit

Supply Voltage 2.7 to 5.25 V

– Built-in LDO regulator

High Speed 8051 µC Core

– Pipelined instruction architecture; executes 70% of instructions in 1 or 2 system clocks

– Up to 25 MIPS throughput with 25 MHz system clock



Memory

– 8/4/2 kB Flash; In-system byte programmable in 512 byte sectors

– 256 bytes internal data RAM

Digital Peripherals

– 16/6 port I/O; push-pull or open-drain, 5 V tolerant

– Hardware SPI™, and UART serial port

– Hardware LIN (both master and slave, compatible with V1.3 and V2.0)

– Three general purpose 16-bit counter/timers

– Programmable 16-bit counter/timer array with three capture/compare modules, WDT

Clock Sources

– Internal oscillators: 24.5 MHz ±0.5% accuracy supports UART and LIN-Master operation

– External oscillator: Crystal, RC, C, or Clock (1 or 2 pin modes)

– Can switch between clock sources on-the-fly

Packages:

– 10-Pin QFN (3 x 3 mm)

– 20-pin QFN (4 x 4 mm)

– 20-pin TSSOP

Temperature Range: –40 to +125 °C
